Lewitt CONNECT 2 USB-C Audio Interface

CONNECT 2 is the most user-friendly audio interface for musicians and content creators. It combines great usability, powerful features, and incredible specs.

Comes with CONTROL CENTER software and all the tools to make you sound sensational with just a few clicks.

Main Features

• USB-C audio interface
• Autosetup for sensational sound with just a few clicks
• Clipguard protects from distortion
• Single-click Compressor and Denoiser
• Three iconic preamp sounds
• Touch-based and intuitive controls
• Custom button for workflow shortcuts
• Individual LED colors and brightness

Autosetup dials in your optimal settings.
With CONNECT 2, you don’t need an audio engineering degree to sound great. Run Autosetup and quickly find your perfect settings with the help of the integrated Clipguard, Denoiser, Compressor, and three iconic preamp sounds.

Easy-to-use tools for perfect sound.

Clipguard
Clipguard lets you perform without clipping. A single click is enough, and your signal is safe from clipping even when things get loud. Fantastic for streaming, podcasting, and recording alike.

Autogain
Autogain is the smart way of gain staging. It sets your input levels for your microphone and instrument automatically, saves time, and ensures optimal recording quality every time your inspiration strikes.

Denoiser
Denoiser uses audio expansion for a clearer signal. It gets background noise and humming out of the way while retaining your natural sound. Ideal for easy communication or recording.

Compressor
Compressor for professional sound quality and a uniform sound image. With CONNECT 2, a single click is enough to get a polished sound, just like your favourite record.

Three iconic preamp sounds for the right vibe.

• Clean gives you unparalleled clarity and fidelity. Perfect if you want to process your signal further.

• Warm provides a vintage vibe and helps to smoothen the high-end of overly bright microphones.

• Vivid brings even your dullest-sounding microphone alive and adds articulation by boosting the right frequencies.

Direct mute control for all channels.
Mute all channels separately on hardware- and software, or if things are getting out of control, hold MUTE to globally mute everything until you reset your channels the way you want.

Custom button for workflow shortcuts.
The custom button lets you assign one of many workflow shortcuts. You can switch from a recording to a monitoring scenario, bring up the CONTROL CENTER with a single push, and more.

The best performance for any microphone.
Whether you choose dynamic or condenser, CONNECT 2 will yield the best results with its high-end microphone preamp. It offers up to 72 dB gain, so you’ll never need an additional signal booster and an incredible dynamic range of 118 dB(A).

Specifications

Device

• Features: RGBW LEDs, MUTE, custom button, autogain, input / playback mix, gain reduction display, Kensington lock
• Control: Capacitive touch
• Inputs: 1x Microphone: balanced 3-pin XLR, 1x Instrument: Hi-Z 6.3 mm jack
• Outputs: 2x Speaker: 6.3 mm balanced jack, 1x Headphone: 6.3 mm jack, 1x Headphone: 3.5 mm jack
• Metering: 25 step high-resolution
• Dimensions and weight: 151 x 110 x 41 mm, 394 g
• Power requirements: USB bus-powered

Digital

• Type: USB-C audio interface
• Software: LEWITT CONTROL CENTER
• DAW included: Steinberg Cubase LE, Cubasis LE
• Compatibility: MacOS, Windows, iOS (plug and play with USB-C devices, devices with lightning connector require Camera Connection Kit and external bus power)
• ASIO driver: Yes
• Sample rate: 44.1 kHz, 48 kHz, 96 kHz
• Bit rate: 24
• USB Audio Class: 2.0
• Signal flow: Input / playback mix
• DSP powered: Yes
• Loopback: Yes
• Inputs / Outputs: 4 (includes 2 software channels) / 2
• Streaming modes: macOS mode, mobile mode
• Min. system requirements: Windows 10 (64 bits): 4 GB RAM minimum, USB 2.0 connector; macOS 10.15 and higher: 4 GB RAM minimum, USB 2.0 connector

Microphone Input

• Features: DSP (low-cut filter, clipguard, preamp modes, denoise, compressor, autogain, autosetup)
• Type: balanced
• Connector: 3-pin XLR
• Phantom power: 48 V
• Gain range: 0 - 72 dB
• Equivalent input noise: –129 dBV (A)
• Dynamic range: 118 dB (A) - Without clipguard 118 dB (A)
• Max input level: 15.8 dBV
• Total harmonic distortion: 0.001%
• Frequency response: 20 Hz - 20 kHz (± 0.1 dB)

Instrument Input

• Features: DSP (low-cut filter, clipguard, preamp modes, denoise, compressor, autogain, autosetup)
• Type: Hi-Z, differential ground loop break circuit
• Connector: 6.3 mm jack
• Gain range: 0 - 60 dB
• Input impedance: 2.5 M Ω
• Equivalent input noise: –108 dBV (A)
• Dynamic range: 121 dB (A) - Without clipguard 105 dB (A)
• Max input level: 12.5 dBV
• Total harmonic distortion: 0.0008%
• Frequency response: 20 Hz - 20 kHz (± 0.1 dB)

Speaker Output

• Features: High volume speaker mode, Mute, Volume, Map system volume controls
• Connector: 2x 6.3 mm jack, balanced
• Frequency response: 20 Hz - 20 kHz (± 0.1 dB)
• Max output level: 12.2 dBV (high volume mode)
• Total harmonic distortion: 0.0023%
• Impedance: 200Ω

Headphone Output

• Features: High impedance headphone mode, Mute, Volume, Map system volume controls
• Connector: 1x 6.3 mm jack, stereo, 1x 3.5 mm jack, stereo
• Frequency response: 20 Hz - 20 kHz (± 0.2 dB)
• Max output level: 6.8 dBV (high impedance mode)
• Total harmonic distortion: 0.003%
• Impedance: 1.9 Ω
