Benchmark DAC3B Digital to Analogue Converter, Black (No Remote)

DAC3B is the most stripped-down model from Benchmark's acclaimed DAC3 D to A converter range. Featuring the same circuit-board and audio path as Benchmark's flagship DAC3 HGC mode.

DAC3B is the most stripped-down model from Benchmark's acclaimed DAC3 D to A converter range. Featuring the same circuit-board and audio path as Benchmark's flagship DAC3 HGC model, the 3B is capable of the same excellent performance every time, and also retains the optional remote capabilities, programmable auto-on and 12v trigger function from its larger brother.
The DAC3B sheds some weight in terms of controls and I/O in comparison to the HGC. Volume control, analogue inputs, mute/polarity controls have all been eliminated along with the headphone amplifier circuit. The bare-bones format of the 3B model makes it a great choice for professional or studio users, and also serves as an excellent partner for existing owners of Benchmarks LA4 line amplifier and HPA4 headphone amp models.

Main Features
• Sample Rate Display
• Word Length Display
• 5 Digital Inputs
• 2 Stereo Analog Outputs (1 RCA, 1 XLR)
• Digital Pass Through
• Native DSD Conversion
• Control-lock Switch
• Asynchronous USB 2.0
• Driverless Asynchronous USB 1.1
• Bi-Directional 12 Volt Trigger
• Power Switch
• Low Power Consumption
• ES9028PRO Converter

Performance
SNR A-Weighted:
125 dB, 128 dB
SNR Unweighted:
123 dB, 126 dB
THD+N:
-114 dBFS, -113 dB, 0.00022% (1 kHz @ -1 dBFS)
Frequency response:
-0.015 dB at 10 Hz (@ Fs=48 kHz)
Crosstalk:
-130 dB at 1 kHz
Max amplitude:
< -144 dB (Jitter inc sidebands)

Physical Properties
Width:
249 mm
Height:
44.5 mm
Depth:
216 mm (behind front panel)
Rackmount:
½ Rack Wide, 1 RU High

Power
Nominal Input Voltage:
100 – 240V (VAC RMS)
Frequency:
50-60 Hz
Idle:
< 0.5 W
Typical Program:
12 W
Fuses:
5 x 20 mm (2 required)
